Author Topic: How-to Downgrade - Upgrade, GB <-> ICS - a tutorial  (Read 27137 times)
AdderV
Guest
« on: March 08, 2012, 11:42:17 AM »

-------------------
<<< I like beer
-------------------
To fully comprehend what is going on in this thread you have to understand a few terms and acronyms.

GB - Gingerbread 2.3.x- the name of the previous software, the Android operative system a.k.a OS.
ICS - Ice Cream Sandwich 4.x - the name of the latest software, the Android operative system.
OTA or actually FOTA - Over The Air, Firmware Over The Air, the way the software update reaches the phone.
ROM - Read Only Memory, the software package for your phone, original a.k.a stock rom, or if it has been altered a custom rom.
RUU - Rom Update Utility - This executable Windows file contains all files you need to restore your phone to original software. It is run from a Windows PC with the phone connected and it will install a clean system on your phone. The original rom comes from such a RUU file and has been extracted from it.
Bootloop - Phone keeps restarting over and over and over and ...
Flashing - Installing something is referred to as flashing
PG58IMG.zip - This type of file is useful when flashing something from hboot, hboot automagically finds this file (because of its name) if it is located on the sdcard and flashes it. It can contain almost anything, such as a new recovery, new hboot, new firmware, new rom etc.
hboot - The bootloader - code that is executed before the Operating System starts to run, during normal use of your phone you'll never see this, but it is possible to restart the phone in bootloader mode to gain access to certain functions.
CID -  Carrier Identifier, a letter and number combination identifying your carrier.
SuperCID - An all powerful CID, using this allows you to use and flash any carrier software without restrictions.
Root - The lowest/deepest level of the operative system. In Windows it's basically C:\ in Linux it's / (Android is Linux).
To gain or have root - To have Superuser or Administrator access rights over the entire OS, you are able to change everything and anything you want.
Unroot - Going back to original software with a locked bootloader and hence S-ON.
NAND - A type of flash memory.
S-ON - Security on, locked NAND memory.
S-OFF - Security off, unlocked NAND memory.
CWM - ClockworkMod, backup and recovery software.
4EXT - Backup and recovery software.
Zip - Certain zip-files, those prepared for it, are installable through a custom recovery.

------------------------------------------------------------------------------------------------------------------

This thread contains info on the following topics:
 - A scenario -  going from custom ICS to stock GB:
 - Reverse scenario -  going from stock unrooted GB to a rooted custom ICS rom:
 - I am on stock software, but rooted and using a custom recovery.
 - Going from stock GB to a stock, rooted ICS via OTA

scroll down to find what you are looking for

------------------------------------------------------------------------------------------------------------------

How to downgrade from a custom ICS to stock GB to get OTA updates?

Q: I'm running a Custom ICS ROM, how do I get back to stock GB rom without risking a boot loop or bricking my phone ?

A: Well it is quite easy and there is not really that big of a risk as long as you have the proper file !

There is no need to fiddle with hboot versions if you downgrade to stock rom using a RUU (rom.zip <-> PG58IMG.zip) !
Why not ? Well, it is all contained in the package, everything will be replaced when you run the "RUU".
Note that you will also get back to stock recovery.

Just make sure that you check the integrity of all and any file you download,
so you don't end up having a damaged copy !  Do md5 sum checks !


A scenario -  going from custom ICS to stock GB:
I am now on HTC ICS 3.32.401.3, rooted and I want to downgrade to stock rom, in my case, this one:
(RUU_Pyramid_HTC_Europe_1.35.401.1_Radio_10.43a.9007.00U_10.51.9007.27_M3_release_198179_signed.exe)

Q: Why that RUU in particular?
A: Because I am in Europe, my CID is HTC__Y13, my stock software was 1.35.401.1, but a newer version will do too, like the 1.50.401.1

First you have to find and download the proper RUU for your phone.

and my device is rooted and the hboot reads:

-Revolutionary-
PYRAMID PVT SHIP S-OFF RL
HBOOT-1.27.1100
RADIO-11.22.3504.07_M
OpenADSP-v02.6.0.2226.00.0131
eMMC-boot
Jan 13 2012,17:33:34




This is what I have done on several occassions and for me it has worked every time:

Short version:
- Backup everything
- Run the proper RUU file


Preparations:

Download all necessary files if you haven't already. Read through and you'll find out which ones you'll need.

First of all I create all sorts of backups using different tools/apps
The backups are not necessarily useful for GB, meaning I can't restore all apps from ICS when on GB !
The same goes for settings, so don't even try to use Titanium Backup to restore all your ICS settings on a GB rom or vice versa !
Those backups are for when you want to go back to the same ICS rom once again i.e. restoring what you had.
Sounds complicated ? It isn't.

Backups:
- 4Ext Recovery Touch, for a complete rom backup
- Titanium Backup, batch backup of all apps and settings
- App Backup & Restore, backup of all apps to folder on sdcard
- Contacts Backup, backups all contacts to file on sdcard

Now copy the entire content of your scard to a folder on your computer,
except for files and folders starting with a (.) period/full stop.


1. Check current CID (CID Getter from Google Play Store), write back the correct CID if you have SuperCID (download, install adb tools), in my case HTC__Y13
2. I have previously extracted the rom.zip* from my RUU_1.35.401.1.exe
3. Rename rom.zip to PG58IMG.zip (rom.zip is the flashable "installer")

Enter your recovery, format everything, and I mean everything, even sdcard!
Stay in recovery! (plug in usb cable) connect usb storage.

* Instead of extracting the rom.zip you could of course run the RUU.exe from Windows with the phone connected in HTC Sync Mode or in fastboot usb. Follow the onscreen directions.
(If you ran the RUU skip to step 9.)

4. Drop the PG58IMG.zip on root of the sdcard (this is the "installer")
5. Reboot phone into hboot
6. hboot finds the file and asks "Do you want to start update?" push "Volume Up" to say yes.
6. Flashing commences, it will take a while, just leave it alone. - I said leave it !
7. When it says: "Update Complete...", "Press <POWER> to reboot." you are good to go, press power and reboot !
8. First boot might take a while ... hands off !
9. Back on stock rom, no root, s-off.


OK ? Got that ? Good !


--------------------------------------------------------------------
But, but ... I want to go the other way ... how do I do that ?

(Oh, my ... *face palm* ...)
--------------------------------------------------------------------



Reverse scenario -  going from stock unrooted GB to a rooted custom ICS rom:

First, do all the backup stuff - again.

Since your phone is now stock, i.e. unrooted you'll have to root it.
Do the Revolutionary bit (revolutionary.io). DO NOT USE "HTCDev Unlock" to unlock bootloader!!
Flash the su-file (superuser) - and you should have super user access to root i.e. "permanently" rooted.

Download all necessary files:
Download the ICS 3.32.401.3.zip (rooted)
Download the proper firmware for this rom. CID number dependant, get it right !
Download the hboot package containing hboot 1.23 and 1.27 and make sure they are the ones with s-off !
Do not flash an hboot with s-on ! You will end up crying if you do.

- Wipe/format everything from the phone and sdcard, stay in recovery !
- Toggle USB storage from recovery
- Drop the custom-rom.zip and the hboot (PG58IMG.zip) on the sdcard
- Reboot to hboot
- Flash hboot 1.23 (with s-off ! get the proper file !) (hboot 1.23 is compatible with both GB and ICS) - reboot to check if hboot 1.23 plays nice with GB. If it does, continue.
Do not take any shortcuts here ! Do not skip to flash hboot 1.27 , you will end up in a bootloop if you do !
- Flash the custom-rom.zip (this one is rooted already) reboot
- Flash hboot 1.27, reboot
- Flash the 3.32.401.* firmware, reboot, Done !

"Extra"
- Install BusyBox (only necessary if you want to install 4Ext Recovery)
- Install 4ext recovery touch (your choice, you already have ClockWorkMod if you rooted through Revolutionary)
         (now copy all your files back to the sdcard-reboot once- let the system settle)
- Restore your previously made 4Ext recovery backup and you will have all your stuff back.

- Get back into Recovery and do a "Fix file permissions"

---------------------------------------------------------------

I am on stock software, but rooted and using a custom recovery.

Can I get the OTA update? Yes, if you are using stock software, no custom ROM-ware, using the correct CID, and a stock recovery then yes you can.

All you have to do is flash the stock recovery included in the RUU file appropriate for your phone.
You either download the stock recovery from the Internet or you extract it yourself.
Run the RUU on a Windows PC, locate the rom.zip in the Temp folder. Move it to another location.
Extract (unzip it*) the rom.zip and inside it you will find the recovery image, flash it using fastboot.
You should be able to get the OTA update now.

Afterwards, if you want to regain root, all you have to do is flash the su-file.zip again.
If you want custom recovery back you can flash that as well.

* I had to use Unversal Extractor to unzip the rom.zip and get to its contents.

-------------------------------------------------------------------------------------------------

Going from stock GB to a stock, rooted ICS via OTA

Q: If I update to ICS using the OTA (over the air) update, can I root it with the Revolutionary tool ?
A: No, that is not possible since Revolutionary isn't compatible with hboot version past 1.18.0000

How to do it then ?

If you want to have your ICS rooted, you root it before the upgrade !

In my case I have received several updates to my phone and the last was 1.50.401.3 <- note that number.

For those paying attention that number will not work for the OTA update since the OTA file number is:
OTA_PYRAMID_ICS_HTC_Europe_3.32.401.5-1.50.401.1_P_release_246627z7pljztztog0er50-2.zip.

So first I had to run the RUU for the phone to get it to that software version. Once on the 1.50.401.1 ->
- root your phone using the Revolutionary tool.
- let Revolutionary flash the custom clockworkmod recovery when it asks to
- flash the su-2.3.6.3-efgh-signed.zip file (SuperUser)

You are now rooted
Reboot the phone check with root checker (it's an app).
If you do not have superuser permissions go back and flash the su-2.3.6.3-efgh-signed.zip again

Download and run Voodoo OTA RootKeeper (it's an app) now and also after the ICS update !

Since you now have a custom recovery you will get the OTA notification but you CAN'T upgrade to ICS ! It will error out !

You have to change back to stock recovery
How to do that and the tools for it is floating around in the forum
Once you have flashed the stock recovery, check for and download the OTA update, let it update
Now you don't have root access, you are rooted but you don't have root access.

Run Voodoo OTA RootKeeper again, "restore root" !

Flash a custom recovery
Go into recovery and flash the su-bin-3.0.3.2-efghi-signed.zip file (Note - file is different from the one above !).

Reboot and check root access. Root Check Basic (it's an app).

Download ROM Manager or 4Ext Recovery Control (requires BusyBox so get BusyBox Installer and install it) and let one of those apps flash an updated recovery for you.

NOTE !
If you aren't able to change back to a custom recovery in adb it might be because the bootloader is now locked !
A locked bootloader shouldn't be a problem regarding flashing but it might.
Check what it says in hboot ! ***LOCKED*** or ***UNLOCKED*** ?

If it is locked, the HTCDev tool is able to unlock it for you.
When you apply the Unlock_code.bin file it will seem like nothing happens, but reboot into hboot and have a look.

If you don't want to use the HTCDev tool, then you'll have to find and flash an unlocked hboot v1.27.0000 from xda-developers forum.

Once ***UNLOCKED***  proceed with flashing a custom recovery using adb and then flash the the su-file.zip again if you have to, using recovery.

« Last Edit: April 27, 2012, 10:09:23 AM by AdderV » Best Screen Protector
mortonch
Newbie
*

Cookies 0
Offline Offline

Posts: 27

Thank You
-Given: 12
-Receive: 0


« Reply #1 on: March 08, 2012, 12:30:10 PM »

Great tutorial. My phone is rooted and I have tried a few different roms. I am a bit nervous about installing an ics Rom though. Tried it before but had problems with the whole hboot thing.  Cry
Best Screen Protector
AdderV
Guest
« Reply #2 on: March 08, 2012, 12:38:49 PM »

Great tutorial. My phone is rooted and I have tried a few different roms. I am a bit nervous about installing an ics Rom though. Tried it before but had problems with the whole hboot thing.  Cry

Thanks !

Flash the hboot 1.23 with s-off and you will be fine.
Best Screen Protector
mortonch
Newbie
*

Cookies 0
Offline Offline

Posts: 27

Thank You
-Given: 12
-Receive: 0


« Reply #3 on: March 09, 2012, 06:02:55 AM »

Tried it last night and it worked fine.

Thanks again
Best Screen Protector
trekdrop
Newbie
*

Cookies 0
Offline Offline

Posts: 4

Thank You
-Given: 0
-Receive: 0


« Reply #4 on: March 22, 2012, 01:05:46 PM »

do i need to do this??

Reverse scenario -  going from stock unrooted GB to a rooted custom ICS rom

i have a
HTC Sensation
 pyramid-1.18.0000
 Android: 2.3.4,
 ROM version 1.50.114.2
Best Screen Protector
AdderV
Guest
« Reply #5 on: March 22, 2012, 01:09:30 PM »

do i need to do this??

Reverse scenario -  going from stock unrooted GB to a rooted custom ICS rom

i have a
HTC Sensation
 pyramid-1.18.0000
 Android: 2.3.4,
 ROM version 1.50.114.2

Need to do what ? Flash hboot 1.23 ? Yes, otherwise you'll bootloop.
1.18 is NOT compatible with ICS.
Best Screen Protector
H3llblax
Newbie
*

Cookies 0
Offline Offline

Posts: 27

Thank You
-Given: 1
-Receive: 0


« Reply #6 on: March 23, 2012, 07:54:56 AM »


Need to do what ? Flash hboot 1.23 ? Yes, otherwise you'll bootloop.
1.18 is NOT compatible with ICS.

Does by flashing hboot 1.23 mean i need to go in recovery n do it?
Best Screen Protector
AdderV
Guest
« Reply #7 on: April 04, 2012, 05:34:31 AM »


Need to do what ? Flash hboot 1.23 ? Yes, otherwise you'll bootloop.
1.18 is NOT compatible with ICS.

Does by flashing hboot 1.23 mean i need to go in recovery n do it?

No the hboot file is renamed to PG58IMG.zip, place it on the sdcard, then reboot phone into hboot.

(But you can actually do it using adb and fastboot as well, just to complicate things Smiley  )
« Last Edit: April 04, 2012, 05:38:04 AM by AdderV » Best Screen Protector
shetc
Newbie
*

Cookies 0
Offline Offline

Posts: 2

Thank You
-Given: 0
-Receive: 0


« Reply #8 on: April 23, 2012, 08:16:47 PM »

First of all, great article -- one of the clearest I've read so far!

Last night, I changed my T-Mobile Sensation from GB to ICS but forgot to export my contact list. I did do a backup from HBOOT before going to ICS. I would like to go back to GB to recover the contact list but I am being prevented from rolling back by the firmware required to install the ICS ROM. Using the instructions in this article, will I be able to rollback to GB and then restore my backup?

Thanks,
Steve
Best Screen Protector
gone
Administrator
SENSATION Fanatic
*****

Cookies 14
Offline Offline

Posts: 2388

Thank You
-Given: 0
-Receive: 180


« Reply #9 on: April 23, 2012, 08:35:16 PM »

First of all, great article -- one of the clearest I've read so far!

Yes, AdderV knows his stuff... think we'll keep 'em   wink
Best Screen Protector
AdderV
Guest
« Reply #10 on: April 24, 2012, 05:52:35 AM »

First of all, great article -- one of the clearest I've read so far!

Last night, I changed my T-Mobile Sensation from GB to ICS but forgot to export my contact list. I did do a backup from HBOOT before going to ICS. I would like to go back to GB to recover the contact list but I am being prevented from rolling back by the firmware required to install the ICS ROM. Using the instructions in this article, will I be able to rollback to GB and then restore my backup?

Thanks,
Steve

Depends, what hboot version is it? 1.27.0000, 1.27.0011, 1.27.1100
Is it ***LOCKED*** and S-ON ?
is it ***UNLOCKED***, or -Revolutionary- and S-OFF?

If unlocked/revolutionary and s-off, yes you can. Otherwise, NO. (well... if you are daring, yes..)

To restore your contacts later, make sure to use an app that is compatible with both GB and ICS, or use the online GMail feature of importing/exporting contacts.

The steps:
-Backup your current ICS system with the custom recovery of your choice.
-Find an early RUU version for your phone (one that does NOT have hboot 1.18.0000), run it (or extract the rom.zip, rename it PG58IMG.zip and flash it from hboot, remove it afterwards)
-Root your phone with Revolutionary, get back to same custom recovery you used when you did the GB backup
-Restore the GB backup, boot, do the Contacts backup

-Flash back stock recovery
-Let the phone do the OTA updates to ICS
-Flash custom recovery
-Flash the su-bin-3.0.3.2-efghi-signed.zip to regain superuser access, might have to do several times
-Restore the ICS backup you did earlier
-Restore the contacts

« Last Edit: April 25, 2012, 07:58:31 AM by AdderV » Best Screen Protector
shetc
Newbie
*

Cookies 0
Offline Offline

Posts: 2

Thank You
-Given: 0
-Receive: 0


« Reply #11 on: April 25, 2012, 08:23:33 AM »

Hi AdderV -- thanks for the reply! My phone is currently Revolutionary and S-OFF. I downloaded RUU_Pyramid_TMOUS_1.50.531.1_Radio_10.56.9035.00U_10.14.9035.01_M_release_223976_signed.exe via the Filefactory. However, I got an Error 155, which seemed to suggest that I was using the wrong RUU. I am with T-Mobile USA -- is there a trick to tell which RUU to use? Also, how do I extract the rom.zip if I wanted to try that approach. Cheers, Steve
Best Screen Protector
AdderV
Guest
« Reply #12 on: April 25, 2012, 08:36:24 AM »

Hi AdderV -- thanks for the reply! My phone is currently Revolutionary and S-OFF.

That is good ! What software are you currently on ? Menu -> Settings -> About -> Software information

I downloaded RUU_Pyramid_TMOUS_1.50.531.1_Radio_10.56.9035.00U_10.14.9035.01_M_release_223976_signed.exe
via the Filefactory.

OK, seems ok, but based on what ?

However, I got an Error 155, which seemed to suggest that I was using the wrong RUU. I am with T-Mobile USA

Try right clicking on the RUU-file.exe and Run as Administrator

-- is there a trick to tell which RUU to use?

You do it by checking the CID (use CID Getter, it's an app), the Software numbers and also in some cases the radio numbers on the original system. If you didn't do that then check the current radio numbers and deduce from that, the above file seems to be correct. Another option is to SuperCID your phone.

Also, how do I extract the rom.zip if I wanted to try that approach. Cheers, Steve

Try this for the rom.zip extraction: http://www.htcsensationforum.com/htc-sensation-rooting/how-to-extract-rom-zip-from-ruu/
« Last Edit: April 25, 2012, 08:46:42 AM by AdderV » Best Screen Protector
androidboy123
Newbie
*

Cookies 0
Offline Offline

Posts: 9

Thank You
-Given: 0
-Receive: 0


« Reply #13 on: May 04, 2012, 05:59:55 AM »

i m on hboot 1.27
i have locked bootloader and s-on
Is there a way to unlock my bootloader or downgrade from ics to gb stock?
Best Screen Protector
AdderV
Guest
« Reply #14 on: May 04, 2012, 06:20:31 AM »

i m on hboot 1.27
i have locked bootloader and s-on
Is there a way to unlock my bootloader or downgrade from ics to gb stock?

You can try the S-OFF method created by Juopunutbear or try the Tacoroot temp root.
Read up on the methods before you do anything.
Best Screen Protector
Pages: [1] 2
Print

Jump to:

Got a new phone? Find the forum here


Related Topics
Subject Started by Replies Views Last post
Google Music Downgrade after UPdate
HTC Sensation Updates
iantang 3 3534 Last post March 15, 2012, 10:46:18 AM
by barkway
How to downgrade from Hboot 1.27.
HTC Sensation Rooting & Custom ROMS
Manitis 4 12996 Last post March 21, 2012, 12:05:19 PM
by Manitis
Downgrade HBOOT 1.18.0000 « 1 2 »
HTC Sensation Rooting & Custom ROMS
H3llblax 21 17658 Last post April 12, 2012, 01:47:56 AM
by AdderV
downgrade from hboot 1.27
HTC Sensation ICS Problems & Questions
androidboy123 2 7980 Last post May 03, 2012, 09:42:50 AM
by androidboy123
ICS upgrade lost my STATUS BAR
HTC Sensation ICS Problems & Questions
HighlanderCFH 0 2037 Last post January 29, 2013, 08:33:33 PM
by HighlanderCFH

Galaxy S3 | Galaxy Note | Galaxy Nexus | Kindle Fire | Atrix 4G | Motorola Xoom | Windows Phone 7
Nokia Lumia | Tech Support Forum | Top Hosts | Samsung Galaxy Tab | Samsung Galaxy S2 | Samsung Galaxy S | Samsung Wave
HTC Evo 3D | HTC Evo 4G | HTC Incredible | HTC Incredible 2 | HTC Incredible S | HTC Thunderbolt
Motorola Droid Razr
| HTC Desire | HTC Desire HD | HTC Desire Z | HTC Desire S | HTC Wildfire
Motorola Droid | Galaxy Indulge | Nokia N8 | Droid Charge | Droid X | Droid X2 | Droid 2| Droid 3 | Fascinate
HTC Sensation | HTC Flyer | LG Revolution | Asus Transformer | Xperia Play | iPhone 4 | Nexus S | Droid Bionic
HTC One | HTC Wildfire S | HTC Droid Eris


This is an Un-Official fan based Website. The views expressed on this website are solely those of the proprietor, or contributors to the site, and do not necessarily reflect the views or opinions of the parties it covers, and is not affiliated with, endorsed or sponsored by parties involved.
If you have a problem with any of the content posted on this website, please contact "mobile@vssupportqueue.com"
Term of Use | Privacy Policy | BlackRain 2006 by, Crip
